Loading IoT Gateway GW-1 (RS485, Wi-Fi, BLE, SIM, RF)
GW-1 IoT Gateway
GW-1 | RS485 | SIM | RF | WiFi BLE | IoT Gateway
Loading price
Loading content
Preparing your HPzenAi experience
Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM)
NewSKU HpzenAi-GW-2
Gateway
IoT Gateway GW-2 - Cellular Connectivity
5.0
Overview
GW-2 is an industrial IoT gateway for HPzenAi field deployments. It combines RS485, Wi-Fi, BLE, SIM connectivity to bridge field devices with cloud dashboards, alerts, and remote automation workflows across utility, water, and agriculture installations.
HPzenAi Price
Loading priceIncl. all Taxes
Quantity
1
Total
Loading price
Free Shipping
Warranty
Secure Pay
01Product Details
Gateway
Product Information
GW-2 is an industrial IoT gateway for HPzenAi field deployments. It combines RS485, Wi-Fi, BLE, SIM connectivity to bridge field devices with cloud dashboards, alerts, and remote automation workflows across utility, water, and agriculture installations.
Hardware
8- ProcessorDual-Core 240 MHz MCU
- Flash Memory16 MB
- RAM8 MB
- Operating Temperature-40°C to +65°C
- Power Supply5V – 12V DC
- RS485 ProtocolModbus RTU
- RS485 CapacityUp to 32 devices per RS485 Segment
- ExpandabilitySupports 1,000+ Devices (Custom Configuration)
Connectivity
5- Wi-Fi2.4 GHz IEEE 802.11 b/g/n
- BluetoothBluetooth 5 Low Energy (BLE)
- RF CommunicationNot supported
- RF RangeNot supported
- Cellular ConnectivityUp to 4G LTE
Software & Connectivity
6- Operating SystemRTOS-Based Firmware
- OTA UpdatesSecure Over-the-Air Firmware Updates
- Cloud ConnectivitySecure Cloud Communications
- Security UpdatesFirmware and Security Support for 10+ Years
- Mobile ApplicationiOS and Android
- Local Data LoggingAvailable as a Custom Feature (Not Included in Standard Version)
Mechanical
4- Enclosure RatingIP65
- MaterialABS Plastic
- ColorWhite
- Mounting OptionsDIN Rail / Wall Mount
Product Measurements
2- Weight0.75 kg
- Dimensions12 × 8 × 4 cm
Hardware
8- ProcessorDual-Core 240 MHz MCU
- Flash Memory16 MB
- RAM8 MB
- Operating Temperature-40°C to +65°C
- Power Supply5V – 12V DC
- RS485 ProtocolModbus RTU
- RS485 CapacityUp to 32 devices per RS485 Segment
- ExpandabilitySupports 1,000+ Devices (Custom Configuration)
Software & Connectivity
6- Operating SystemRTOS-Based Firmware
- OTA UpdatesSecure Over-the-Air Firmware Updates
- Cloud ConnectivitySecure Cloud Communications
- Security UpdatesFirmware and Security Support for 10+ Years
- Mobile ApplicationiOS and Android
- Local Data LoggingAvailable as a Custom Feature (Not Included in Standard Version)
Product Measurements
2- Weight0.75 kg
- Dimensions12 × 8 × 4 cm
Connectivity
5- Wi-Fi2.4 GHz IEEE 802.11 b/g/n
- BluetoothBluetooth 5 Low Energy (BLE)
- RF CommunicationNot supported
- RF RangeNot supported
- Cellular ConnectivityUp to 4G LTE
Mechanical
4- Enclosure RatingIP65
- MaterialABS Plastic
- ColorWhite
- Mounting OptionsDIN Rail / Wall Mount
02Package Lists
Included
Package Lists
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) package item - Gateway unit
Gateway Unit
Primary gateway hardware for field installation and device communication.
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) package item - Installation Guide
Installation Guide
Reference guide for setup, installation, commissioning, and basic service checks.
03Use Cases
Applications
Use Cases
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) use case - Agriculture Sensors
Agriculture Sensors
Connects HPzenAi agriculture sensors for field telemetry, threshold alerts, and irrigation-oriented monitoring workflows.
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) use case - Water Meters
Water Meters
Aggregates HPzenAi water meter data for consumption tracking, remote visibility, and distribution management.
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) use case - Level Sensors
Level Sensors
Bridges HPzenAi level sensors to cloud dashboards for tank, sump, and borewell monitoring workflows.
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) use case - Energy Meters
Energy Meters
Collects HPzenAi energy meter readings for electrical consumption visibility, panel monitoring, and reporting.
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) use case - Motor Controller
Motor Controller
Links HPzenAi motor controllers for remote status monitoring, automation rules, and pump-control workflows.
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) use case - Relay Controller
Relay Controller
Coordinates with HPzenAi relay controllers for multi-output switching, panel automation, and remote command execution.
- Loading IoT Gateway GW-2 (RS485, Wi-Fi, BLE, SIM) use case - Valves
Valves
Supports HPzenAi valve control workflows for line switching, pressure management, and remote water distribution control.
04Warranty
Support
Warranty
Warranty Period
12-month limited warranty
Coverage
- Manufacturing defects under standard use conditions
- Internal electronics and sensor faults verified by support
- Factory accessory issues reported within the covered service window
Service
- Remote diagnostics and guided troubleshooting from HPzenAi support
- Service request coordination for repair or replacement review
- Availability of spare parts during service life
Replacement
Eligible direct orders can be reviewed for replacement support for verified transit damage or early manufacturing defects under the applicable policy.
